Wilwood Forged Superlite 4-Piston Radial Mount Calipers – Lightweight Aluminum Braking System

Description

Brand: Wilwood Disc Brakes
Manufacturer’s Part Number: 120-14056-RD
Part Type: Brake Calipers
Product Line: Wilwood Forged Narrow Superlite 4 Radial Mount Calipers
Automotive Fittings Part Number: WIL-120-14056-RD
UPC: 889545071252
Caliper Series: Forged Narrow Superlite 4 Radial Mount
Caliper Piston Quantity: Four
Piston Diameter (in.): 1.380
Rotor Thickness (in.): 1.100 in.
Caliper Material: Aluminum
Caliper Color: Red
Caliper Logo: Wilwood
Parking Brake Provision: No
Fittings Included: No
Thread Size: 1/8 in. NPT
Brake Pads Included: No
Brackets Included: No
Remanufactured: No
Quantity: Sold individually.
Notes: Accepts up to 14 in. rotor diameter.
Description:
Wilwood Forged Narrow Superlite 4 radial mount calipers are a new version of Wilwood’s venerable Superlite caliper series. They add versatility and the convenience of radial mounting to this widely popular caliper series. Radial mounting simplifies adaptation and provides two planes of adjustment for accurate alignment over the disc. These calipers integrate “Big Brake” style with Wilwood’s latest technology to generate big stopping power in extreme environments.
