Description
Features:
- Low Noise Preamplifier Circuit – Q-Stasis Pre Amplifier Stage: Maximum low voltage signal from the source unit comes into the amplifier circuit with minimal distortion.
- High Level Inputs – DC SIGNAL SENSE: The DC SIGNAL SENSE switch will allow the amp to turn on when a signal is received on the RCA inputs, so an amplifier remote turn on wire is not needed to turn on the amplifier. This feature can also be turned off.
- LED System Protection Circuitry Diagnostics – Monitor overload and speaker short protection with illuminated indicators on the amplifier end panel.
Specifications:
- Amp Total Channels: 4
- Amp Max Power (watts): 400
- Amp Power @ 2 Ohms (ch x watts): 4 x 100
- Amp Power @ 4 Ohms (ch x watts): 4 x 50
- Amp Mono Bridged @ 4 Ohms (ch x watts): 2 x 200
- Amp Variable High Pass Crossover 12dB per Octave: 40Hz-400Hz
- Amp Tone Control / Parametric EQ: Built-in Bass Control
- Amp Subsonic Filter: 10Hz-40Hz
- Amp Variable Voltage: 0.2-12V
- Amp Frequency Response: 10Hz-500Hz
- Amp Total Harmonic Distortion (THD): 0.1%
- Amp Fusing: 40 Amp
- Amp Class: Class D
- Dimensions: 10.43 × 7 × 3.23 in
- Sold Each
