The Eventuri Stage 3 intake system for the 8V RS3 Gen 2 and TTRS 8S is engineered to deliver maximum airflow while maintaining the lowest possible intake temperatures. Designed to support high-powered builds, this system flows 840 CFM—a 58% improvement over the restrictive stock airbox—while the sealed design prevents engine bay heat soak that compromises performance.
Each component has been meticulously designed to provide the turbo with a smooth and free-flowing path. The patented Venturi housing uses aerodynamic principles to accelerate airflow while maintaining laminar conditions, eliminating turbulence that plagues conventional cone filter setups.
Key Features:
- 103mm internal diameter intake tube with smooth curvature minimizing pressure drop
- 210mm diameter bespoke high-flow cone filter with 130,000mm² filtration surface area
- Patented carbon fiber Venturi housing invoking laminar flow principles
- Sealed design with elevated hood scoop providing equivalent to 7″ diameter extra cold air entry
- 100% pre-preg carbon fiber construction eliminating fibreglass resin imperfections
- Gold reflective heat shield protecting carbon tube from turbo radiation and convective heat
- Compatible with both DAZA and DWNA engines (2019 OPF versions supported)
- ISO-tested dry cone filter maintains OEM filtration standards
Performance Notes:
- +15-18hp on stock turbo RS3; +25-30hp with hybrid turbo
- +19-23ft-lb torque (stock turbo); +20-24ft-lb (hybrid turbo)
- Flow bench verified 840 CFM at 28″ H2O versus 530 CFM stock airbox
- Supports over 1000whp on full frame turbo builds
- Enables lower boost requirements compared to competing systems
Includes:
- Carbon fiber Venturi filter housing with 103mm outlet
- Bespoke high-flow dry cone filter (210mm OD)
- Carbon fiber inlet duct with flexible rubber seal
- Smooth-curve carbon fiber intake tube (103mm ID)
- Heat shield with gold reflective backing and stainless steel brace
- OPF (DWNA) breather adapter for 2019+ applications
- Laser-cut stainless steel mounting brackets
- Silicon breather hose and couplers
- Installation guide and all required hardware
Maximum airflow. Minimum temperatures. Unlimited potential for the RS3 8V and TTRS 8S.
