Description
- Total Max Power: 600W
- Amplifier Type: Class-A/B
- Channel Design: 4/3/2 Channel
- Thermal Control: Thermal Management Control
- Power Supply: DC-DC PWM Power Supply
- Power Supply Design: MOSFET Power
- Current Protection: Over-Current, Over-Voltage and Thermal Protection
- Crossover: Variable Low-Pass / High-Pass
- Green/red status LED
- 2 pair RCA pre-inputs
- RMS Rating
- Per Channel into 4ohms (≤1%THD+N): 4 x 50W
- Per Channel into 2ohms (≤1%THD+N): 4 x 70W
- Bridged into 4ohms (≤1%THD+N): 2 x 130W
- Sound Tuning
- Crossover Frequency (Variable, OFF/LPF/HPF Selectable)
1/2 Ch: LP/HP: 50Hz – 500Hz
3/4 Ch: LP/HP: 50Hz – 500Hz - EQ (Equalizer): Bass EQ Fixed Frequency 45 Hz, Q=0.5, Variable Gain 0dB to +12dB (3/4 Ch only)
- Dimensions
- Footprint: 330 mm x 52 mm x 240 mm
